Conducted EMI vs. Radiated EMI — What’s the Difference?

Electromagnetic interference (EMI) is a phenomenon that often occurs when electrical devices are exposed to external electromagnetic (EM) fields. In some cases, exposure to EMI can lead to component degradation or even cause devices to stop working. Depending on the electronic device and the application, that can mean anything from mounting costs and unplanned downtime to complete data losses and total electrical disasters.

Explore EMI/EMC Filters

EMI may be continuous or pulsed and generally comes from one of two sources:

  • Human-made EMI: This EMI is created by human-made devices like power lines, lights, computers, and radios.
  • Natural EMI: Natural EMI comes from many sources, including electrical storms, cosmic noises, and solar radiation.

When devices come into contact with these electromagnetic fields, they become receivers. The exposure can be direct (conducted EMI) or indirect (radiated EMI).

What Is Conducted EMI?

Interference transferred from a source to a receiver along a direct route is called conducted EMI. This method requires a physical conduction route that transfers electromagnetic emissions to connected equipment. Common paths for conducted emissions include power cables and electrical interconnection cabling. It can also occur through parasitic capacitance.

EMI conduction occurs in two modes, common and differential.

What Is Common Mode EMI?

  • Common mode: Common-mode EMI signals appear simultaneously on two receiver lines. They are in the same direction and phase as the signal lines, and each returns to a common ground.

What Is Differential Mode EMI?

  • Differential mode: Differential-mode EMI appears on closed-loop circuits, with the electrical current flowing in directions opposite the signal line. This interference materializes in series with the generated signal.

What Are Common Sources of Conducted EMI?

There are many sources of conducted EMI. Some of the more common include:

  • Electrical motors
  • Switch-mode power supplies
  • DC/DC converters
  • Thermostatically controlled appliances
  • Micro-controllers
  • Ethernet traffic

What Is Radiated EMI?

Unlike conducted EMI, radiated EMI requires no physical contact — it travels through the air instead. These emissions happen when devices produce intentional or unintentional electromagnetic energy in the form of an electrical field. Damage from EMI-radiated emissions occurs through induction. Radiated emissions spread outward, sometimes traveling long distances. Depending on their proximity and severity, they can have unwanted impacts on receiving devices located within the vicinity. These electrical emissions can also interfere with the source device operation if they overwhelm the circuitry.


What Are Common Sources of Radiated EMI?

Virtually all electrical devices produce a degree of radiated EMI, including mobile devices and children's toys. Common sources of significant interference include:

  • Radar systems
  • Electrical motors
  • Switch-mode power supplies
  • DC/DC converters
  • AM/FM radio signals
  • Power transmission lines
  • Telecommunications equipment
