New High Density Open Frame AC/DC Power Supply from Astrodyne TDI Provides 400 Watts at 92% Efficiency


Mansfield, Mass. – December 2015 – Astrodyne TDI, a global developer and manufacturer of specialized power solutions, introduces a high density open frame AC/DC power supply that provides 400 Watts of regulated power in a 3×5 form factor. The power density of the ASM400 series results in a small footprint, making it extremely flexible for use in powering portable medical equipment and numerous industrial applications.

medical_powersupply

The ASM400 series is certified to IEC60601-1 3rd edition BF isolation as a Class I (grounded) input, with a Class II (non-grounded) input and 2 MOPP option. This power supply series is especially useful for portable home medical use and direct connect patient life-sustaining applications including infusion pumps, ventilators and portable dialysis machines.

Designed with over 50 years of medical power experience, and built in the Astrodyne TDI ISO13485 certified factory, the ASM400 series features a 5V auxiliary and 12V fan output with efficiency up to 92% at 230VAC.

Technical Specifications

  • 400 Watts of regulated DC power in a miniature 3” x 5” x 1.4” (76mm x 127mm x 36mm) footprint
  • Medical Safety Certified IEC60601-1 3rd Edition
  • 5V auxiliary and 12V fan output
  • Remote On signal
  • Custom output voltages available
  • High efficiency up to 92% at 230VAC
  • High density power up to 19W/inch³

For high res download and full text: http://www.simongroup.com/PressRoom/press-release.php?Job=AST-A-45045

Access our blog: https://www.astrodynetdi.com/news
